2SA934

Type Designator: 2SA934

Material of Transistor: Si

Polarity: PNP

Maximum Collector Power Dissipation (Pc): 0.75 W

Maximum Collector-Base Voltage |Vcb|: 40 V

Maximum Emitter-Base Voltage |Veb|: 5 V

Maximum Collector Current |Ic max|: 0.7 A

Max. Operating Junction Temperature (Tj): 175 °C

Transition Frequency (ft): 150 MHz

Collector Capacitance (Cc): 20 pF

Forward Current Transfer Ratio (hFE), MIN: 80

Noise Figure, dB: -

Package: TO92
