2SC1545

Type Designator: 2SC1545

Material of Transistor: Si

Polarity: NPN

Maximum Collector Power Dissipation (Pc): 0.3 W

Maximum Collector-Base Voltage |Vcb|: 40 V

Maximum Emitter-Base Voltage |Veb|: 6 V

Maximum Collector Current |Ic max|: 0.3 A

Max. Operating Junction Temperature (Tj): 150 °C

Transition Frequency (ft): 125 MHz

Collector Capacitance (Cc): 3 pF

Forward Current Transfer Ratio (hFE), MIN: 10000

Noise Figure, dB: -

Package: TO106
