2SD882-AZ/SM TO-126 3A 40V NPN TRANSISTOR
0 - Yorum
Kategori
Kalan Adet
1700 Adet
Fiyat
0,18 USD + KDV
*0,85 TL den başlayan taksitlerle!
9,09 TL
2SD882 TO-126 40V 3A NPN TRANSISTOR
2SD882
Type Designator: 2SD882
Material of Transistor: Si
Polarity: NPN
Maximum Collector Power Dissipation (Pc): 10 W
Maximum Collector-Base Voltage |Vcb|: 40 V
Maximum Collector-Emitter Voltage |Vce|: 30 V
Maximum Emitter-Base Voltage |Veb|: 5 V
Maximum Collector Current |Ic max|: 3 A
Max. Operating Junction Temperature (Tj): 150 °C
Transition Frequency (ft): 90 MHz
Collector Capacitance (Cc): 45 pF
Forward Current Transfer Ratio (hFE), MIN: 60
Package: TO126
Bu ürüne ilk yorumu siz yapın!
