AUIRG4PH50S TO-247AC 1200V 141A IGBT TRANSISTOR
₺914,76 + KDV
50 Adet Stokta var, şimdi sipariş ver hemen kargoda
Kategori
Marka
Stok Kodu
IGBT-4075
Fiyat
914,76 TL + KDV
*102,06 TL den başlayan taksitlerle!
|
Category
|
Gate Charge
227 nC
|
|
Manufacturer
Infineon Technologies
|
Td (on/off) @ 25°C
-/616ns
|
|
Packaging
Tube
|
Test Condition
600V, 33A, 5Ohm, 15V
|
|
Part Status
Obsolete
|
Operating Temperature
-55°C ~ 150°C (TJ)
|
|
Voltage - Collector Emitter Breakdown (Max)
1200 V
|
Grade
Automotive
|
|
Current - Collector (Ic) (Max)
141 A
|
Qualification
AEC-Q101
|
|
Current - Collector Pulsed (Icm)
99 A
|
Mounting Type
Through Hole
|
|
Vce(on) (Max) @ Vge, Ic
1.7V @ 15V, 33A
|
Package / Case
TO-247-3
|
|
Power - Max
543 W
|
Supplier Device Package
TO-247AC
|
|
Switching Energy
16mJ (off)
|
Base Product Number
|
|
Input Type
Standard
|
Bu ürüne ilk yorumu siz yapın!
Ürün hakkında henüz soru sorulmamış.
Ürün Bilgisi
|
Category
|
Gate Charge
227 nC
|
|
Manufacturer
Infineon Technologies
|
Td (on/off) @ 25°C
-/616ns
|
|
Packaging
Tube
|
Test Condition
600V, 33A, 5Ohm, 15V
|
|
Part Status
Obsolete
|
Operating Temperature
-55°C ~ 150°C (TJ)
|
|
Voltage - Collector Emitter Breakdown (Max)
1200 V
|
Grade
Automotive
|
|
Current - Collector (Ic) (Max)
141 A
|
Qualification
AEC-Q101
|
|
Current - Collector Pulsed (Icm)
99 A
|
Mounting Type
Through Hole
|
|
Vce(on) (Max) @ Vge, Ic
1.7V @ 15V, 33A
|
Package / Case
TO-247-3
|
|
Power - Max
543 W
|
Supplier Device Package
TO-247AC
|
|
Switching Energy
16mJ (off)
|
Base Product Number
|
|
Input Type
Standard
|
